Header 2 Horse Straight Load Float 2hsl Wb
2HSL-WB
Build to order

2 Horse Straight Load Float Wide Body With kitchen

$26,000.00

Factory direct price.

HORSES

2

LOAD TYPE

Straight Load

Designed with larger horses in mind, the 2 Horse Straight Load Wide Body with Kitchen combines generous horse space with practical facilities for riders spending long days at competitions, clinics and events.

The extra-wide, extra-long bays provide more room for larger horses, while the straight-load configuration offers a familiar and straightforward travelling setup. Twin access doors and fold-up bay beds add flexibility and make it easier to access and use the float when you arrive at your destination.

At the front, the integrated kitchen provides a convenient space for preparing food and drinks, with useful storage and everyday appliances already incorporated into the design. Dedicated saddle and rug storage helps keep your equipment organised and separate from the main horse area.

Built on Pinnacle’s heavy-duty galvanised chassis with tandem suspension and electric braking, this model combines robust construction with the extra space and practical features needed for regular travel. It’s an ideal choice for owners of larger horses who prefer a straight-load configuration without sacrificing the convenience of an integrated kitchen.

Get a quote
Call 1800 214 334

Finance is available through our finance partner iCredit. Ask us, or call iCredit on 1300 350 118.

Australia wide delivery

Australia wide delivery

2 year frame warranty, 12 months on moving parts

2 year frame warranty, 12 months on moving parts

Download spec sheet (PDF)

Specifications

Windows & Doors

  • Front window 1 x 1220 x 610
  • Roof fully moulded
  • Rooftop vents x 2

Wheels & Tyres

  • Heavy duty 18R14c light truck tyre
  • Wheels 14″ alloy rims

Axles & Suspension

  • Axles solid 2 x 50 x 50 RHS, 4 wheel electric braked axle
  • Brakes – full twin axle electric brakes with “Brake Away System”
  • Nuts and bolts – all stainless steel
  • Suspension – 8 leaf roller rocker tandem spring axles

Chassis & Frame

  • Body panels galvanised 1.2mm
  • Double dipped galvanised RHS 4mm chassis
  • Frame double dipped RHS 2.5mm

Lighting

  • Rear lights – LED
  • Retro reflectors x 8 units
  • Side lights x 6 units
  • Trailer plug – square seven pin

Dimensions (L x W x H)

  • Size of ramp door – 2020 x 1210
  • Size of side door – 1755 x 615
  • Body dimensions – 4095 x 1800 x 2230
  • Inner dimensions – 4070 x 1930 x 215
  • Internal height – 2200mm
  • Overall dimensions – 4945 x 2280 x 2590
  • Size of bays – 240cm long x 80cm wide between padding

Weight

  • Gross – 3500kg
  • Tare – 1600kg

Standard Inclusions

  • 12v/240 volt built in fridge and 240v microwave
  • Twin Access Doors (one on each side)
  • AluminuimKitchen with self closing drawers and wardrobe
  • Front Opening Saddle Rack
  • Foldup bay beds
  • Drawbar checker plate 1.2mm
  • Floor rubber matting – 10mm
  • 26mm Composite Flooring
  • Horse protection frame – fully padded
  • Rear door hitches – 6mm copper hinges
  • Rubber matting for horse door – 28mm ribbed rubber matting
  • Rubber matting inner side panels – 6mm rubber matting
  • Rug rack – full length overhead
  • Side horse rings x 4

Get a quote

Request a quote

"*" indicates required fields

This field is for validation purposes and should be left unchanged.

Optional extras

Talk to our team about which features can be added to your float or gooseneck, and which upgrades would be suitable.

More Options
